TRIGON ADVANCE II SE Black

Phono stage for MM and MC systems. Externally accessible dip-switches allow perfect matching of gain, impedance and capacitance to suit a wide range of phono cartridges. Its external power supply allows to install the Vanguard III phono stage near the turntable, maintaining a short and direct signal path while minimizing interference.

- Affordable high value – excellent sound and outstanding built quality!

Technical data
Reinforcement:    Adjustable from 36 to 60 dB in 16 steps
Additional reinforcement: +12dB (resulting in a maximum gain of 72dB)
Input resistance: from 25 ohms to 1800 ohms in 31 steps; 47 kOhms
capacity: Base capacitance = 60 – 100pF
Switchable capacitance: = 47pF, 100pF, 147pF
Entrance: 1x RCA
Exit: 1x RCA
Signal-to-noise ratio: -72dB at 60dB gain and-94dB at 36dB gain
Frequency response: ±0.2 dB RIAA equalized
Total harmonic distortion: (THD + N)    0.06%
Crosstalk attenuation: -96.2 dBA at 10 kHz
power consumption: 7-10VA depending on the battery's charge level
Warranty service: 3 years (except for batteries = ½ years)
Dimensions H x W x D: 58.5mm x 200mm x 320mm
