CARY AUDIO DESIGN V12R CAD-280-SA

Usato, in ottime condizioni, privo di segni di usura evidenti. Privo di imballo originale.
Finale di potenza a valvole

Specifiche tecniche
DIMENSIONS: 9’’H x 12 _’’W x 20’’D
WEIGHT: 68-lb. stereo or 85-lb. for the Monobloc version
CIRCUIT TYPE: Push-Pull Triode or Ultra-linear Amplification in Pure Class A
POWER OUTPUT: 50 watts - Triode Mode 100 watts - Triode (Mono)
100 watts - Ultralinear Mode 200 watts - Ultralinear (Mono)
INPUT SENSITIVITY: 1.3 volts for full output
INPUT IMPEDANCE: 150,000 ohms
NOISE AND HUM: > 84db below rated output
FREQUENCY RESPONSE: 20Hz to 23Khz +/- 1.0 dB (at full power)
TUBES: 2- 12BZ7 Input tubes (or 12AY7, 12AX7)
2- EL-84 Current Source tubes (or 6BQ5)
12- EL-34 Output tubes (or 6550, KT-66, KT-77, KT-88, KT-
90, 6L6)
POWER TRANSFORMER: 1- EI laminated, 200% duty cycle
OUTPUT TRANSFORMERS: 2-EI laminated stereo (1-EI mono) Silicon Impregnated
RESISTORS: 1.0% tolerance, precision metal film resistors
CAPACITORS: Oil Filled
POWER SUPPLY CAPACITORS: 4 - 560 MFD @ 400 volts
AC CORD: 3 conductor shielded detachable
AC POWER REQUIREMENTS: 117/234 volts AC 50/60Hz
POWER CONSUMPTION: 420 watts in operation, 10 watts in stand-by
WARM-UP TIME: 3 minutes
BREAK-IN PERIOD: 100 hours of music playing time
FINISH: Jaguar Carnival Red paint on chassis
FRONT PANEL: Machined, Black Anodized aluminum
Specifications are subject to improvement without notice or obligation.
