YAMAHA NS-800A

AN UNMATCHED IMMERSIVE SOUND
By combining striking aesthetics with cutting-edge technology, Yamaha—also a leader in musical instruments—has created the compact NS-800A speaker. Its exclusive Harmonious Diaphragm™ produces an incredibly unified tone, while the large, high-capacity structure delivers deep, immersive sound dispersion. Finally, its refined finish recalls grand pianos, offering a truly luxurious listening experience.

DYNAMICS
Rather than simply producing powerful sound, we aim for a sense of dynamics that expresses the contrast between stillness and movement in music, so you can hear the deep emotions of sound and become immersed in that musical world.

PERFECT SOUND PERFORMANCE
A true jewel of the flagship series, the NS-3000 features top-quality components in its crossover circuit. The MCap® SUPREME EVO audio capacitor made by the German company Mundorf, renowned as one of the best capacitors for audio use, is paired with a large woofer coil.

HIGH-QUALITY COMPONENTS
The speaker terminals feature an original design with a shape that comfortably fits the fingers, allowing screws to be tightened easily while maintaining an elegant appearance.

NS-800A
The NS-800A is an exclusive 2-way speaker that reproduces the exact timbre of all musical instruments for a wide soundstage.

• Compact 2-way speaker with 16 cm woofer
• New Harmonious Diaphragm™ made from a combination of Zylon® and spruce for perfect tonal balance
• Ideal cabinet structure designed using vibration analysis technology developed for musical instrument manufacturing
• Yamaha patented acoustic damper optimized for the NS-800A
• Yamaha patented R.S. (Resonance Suppression) structure to eliminate unwanted resonance
• Authentic piano-inspired finishes for an elegant touch
• High-quality crossover components, including audio capacitors made by Mundorf in Germany
• Robust brass speaker terminals for highly secure connections and a refined appearance

The NS-800A is an exclusive 2-way speaker that reproduces the exact timbre of all musical instruments for a wide soundstage.

• Compact 2-way speaker with 16 cm woofer
• New Harmonious Diaphragm™ made from a combination of Zylon® and spruce for perfect tonal balance
• Ideal cabinet structure designed using vibration analysis technology developed for musical instrument manufacturing
• Yamaha patented acoustic damper optimized for the NS-800A
• Yamaha patented R.S. (Resonance Suppression) structure to eliminate unwanted resonance
• Authentic piano-inspired finishes for an elegant touch
• High-quality crossover components, including audio capacitors made by Mundorf in Germany
• Robust brass speaker terminals for highly secure connections and a refined appearance

Technical specifications:

Type: 2-way bass-reflex
Woofer: 16 cm (6-1/2″) cone type
Tweeter: 3 cm (1-1/4″) dome type
Frequency response: 40 Hz–65 kHz (-10 dB); up to 100 kHz (-30 dB)
Input power: 40 W nominal; 120 W maximum
Sensitivity: 86.5 dB
Crossover frequency: 2.6 kHz
Impedance: 6 ohms; minimum 3.8 ohms
Dimensions (W x H x D): 231 x 420 x 358 mm; 9-1/8″ x 16-1/2″ x 14-1/8″
Weight: 13.0 kg; 28.7 lbs
