CYRUS CLASSIC AMP 2

The Classic AMP is the latest update to an integrated amplifier that has been part of the Cyrus product range for over a decade.

This integrated amplifier provides a significant step up in performance from previous versions by using everything that we learnt when developing the fantastic XR Series, but retaining the familiar design of the Classic series. The circuit design has been completely re-designed and the majority of the internal components have been upgraded by the Cyrus R&D team, which has resulted in sound improvements that will help the Classic series retain a loyal fan base for years to come.

Power amplifier
The power amplifier delivers 91W per channel into 6?. The wideband design responds from D.C. to beyond 50kHz to ensure a flat frequency response and minimal phase shift through the audio band.

Technical specifications:
Type: Stereo integrated amplifier
Power: 2x70 W into 8 ohms, 2x91 W into 6 ohms, 2x112 W into 4 ohms
THD+N: <0.002% (1kHz, 2/3 power) 6 Ohms
Input sensitivity: 225 mV (91W/6Ω)
Input Impedance: 28 kohm
Max input signal: 2.5V
Frequency response: <0.5Hz - 50kHz (-3dB)
S/N ratio: >100 dB
Analog inputs: 4 line level
Phono input: MM for vinyl turntables
Digital inputs: 2x Coaxial via RCA (24bit/192kHz)
Optical digital inputs: 2x via Toslink (24bit/192kHz)

PHONO FEATURES:
Input Sensitivity: 2.3 mV (91W/6Ω)
Input Impedance: 47 kohm
Max input voltage: 25 mV (1kHz)
Phono stage gain: 80 dB (1kHz)
RIAA tolerance: <0.5 dB
S/N ratio: 83 dB (ref. 91W/6Ω, vol -6dB)
THD: <0.07%

DIGITAL AUDIO PERFORMANCE:
Input voltage: 500mV pk-pk
Input Impedance: 75Ω
Sample rate range: 32k – 192k
Audio formats: PCM stereo only
S/N ratio: -94 dB (0dB fs)
THD+N: <0.006% (0dB fs)

CHARACTERISTICS SEC. HEADPHONES:
Headphone output: 3.5mm jack
Recommended headphone impedance: 16 - 330 ohm
Output power: 138 mW (16 ohm load)
Max output voltage: 1.85 V (330 ohm load)
S/N ratio: 90 db (35mW/16 ohm)
THD: <0.01% (35mW/16 ohm)

GENERAL:
Power Supply Voltage: 230V
Consumption: Standby <0.5 W - Max 500 W
Dimensions: 215 x 75 x 365 mm (WxHxD)
