MAGNAT HUMIDOR

Price referred to the product on display

High-end 2-way shelf-top speaker with genuine cedar wood veneer

- Emphatically compact and very high-quality high-end shelf-top speaker
- Highly resilient long excursion bass mid-range speaker and fine silk dome for the highest sound precision
- Particularly stylish looks with two-tone cedar real wood veneer and metal applications
- Klippel® optimisation for extremely low distortion at all volumes
- High-end- hi-fi in the smallest of places: ideal for cramped conditions without a subwoofer

The Magnat Humidor offers absolute top technology in an extremely compact shelf-top speaker format. High-quality drivers with an aluminium-ceramic sandwich membrane (subwoofer) as well as a special silk dome (tweeter) ensure, in combination with the other high-quality components, a top-class acoustic experience. The Humidor is also very attractive visually, presenting a stylish appearance with its two-tone genuine cedar wood veneer. Meticulous coordination and tuning, laser-assisted measuring with the Klippel system, high-quality components and a striking, stylish appearance make the Humidor an exceptional speaker that also fits into any living room in a perfectly harmonious way.


Highlights

Midrange-woofer
- Airflow-optimized, non-magnetic aluminium die-cast basket to prevent turbulence and compression effects to handle large cone excursions
- Distortion-optimised, powerful magnet system with induction ring and stray field optimisation, thereby ensuring minimal distortion and high efficiency
- Kapton voice coil to minimise eddy current loss, thereby ensuring minimal distortion of the midrange and optimised efficiency
- Aluminium/ceramic sandwich cone with an inverted dust cap for optimum rigidity with high internal damping

Tweeter
- Silk dome tweeter with a particularly wide surround for optimised dispersion characteristics at frequencies above 20 kHz
- Special sound guide in the aluminium front panel for optimum dispersion properties
- High performance neodymium magnet system for excellent dynamics and a high resolution

Crossover
- Elaborated phase and amplitude optimized crossover with selected high-quality components
- Particularly low-impedance bass-midrange channel for minimal electrical loss

Cabinet
- Sturdy MDF cabinet with two-tone cedar real wood veneer
- Solid metal sound guides for the woofer-midrange and tweeter
- Inlaid logo on the top of the enclosure
- All metal parts in harmoniously matched champagne colour
- Reinforcing board in the housing with chassis support for the bass-midrange, which ensures optimum low-resonance properties and minimal intrinsic vibration

Cabinet surface
Two-tone cedar real wood veneer, metal applications in champagne colour


Specifications
Principle: High-End-Bookshelf Speaker
Equipment: 25 mm dome tweeter 110 mm woofer-midrange
Power Handling (RMS/Max.): 75 / 150 watts
Sensitivity (2.8V/1m): 90 dB
Impedance: 4 - 8 Ω
Frequency Response: 34 - 50000 Hz
Crossover Frequencies: 2500 Hz
Recommended Amplifier Output: > 30 Watts
Dimensions (WxHxD): 140 x 245 x 258 mm
Weight: 4.5 kg
